A 100 Gigabit switch for enterprise networks and data centers. Hot-swappable parts and insane port density with 1.2 Tbps switching capacity!
With 2x 100 Gigabit QSFP28 ports and 16x 25 Gigabit SFP28 ports, this is the perfect cost-effective addition to any enterprise network or data center. And with dual-redundant hot-swappable power supplies and fans, you won’t have to worry about unnecessary downtime.
The 25-gigabit ports are backward compatible with 10 Gigabit and 1 Gigabit SFP devices. Mix and match as you need!
<iframe class="ql-video" frameborder="0" allowfullscreen="true" src="https://www.youtube.com/embed/nlhEcesjxiw?showinfo=0"></iframe>
Specifications
Details
Product code: CRS518-16XS-2XQ-RM
Architecture: MIPSBE
CPU: QCA9531
CPU core count: 1
CPU nominal frequency: 650 MHz
Switch chip model: 98DX8525
RouterOS license: 6
Operating System: RouterOS v7
Size of RAM: 64 MB
Storage size: 16 MB
Storage type: FLASH
MTBF: Approximately 200'000 hours at 25C
Tested ambient temperature: -40°C to 70°C
Powering
Details
Number of AC inputs: 2
AC input range: 100-240
Frequency (Hz): 47-63
Max power consumption: 95 W
Max power consumption without attachments: 45 W
Cooling type: 4 fans
Ethernet
Details
10/100 Ethernet ports: 1
Fiber
Details
Number of 25G SFP28 ports: 16
Number of 100G QSFP28 ports: 2
Peripherals
Details
Serial console port: RJ45
Number of USB ports: 1
USB Power Reset: Yes
USB slot type: USB type A
Max USB current (A): 1
Other
Details
PCB temperature monitor: Yes
Voltage Monitor: Yes
Certification & Approvals
Details
Certification: CE, EAC, ROHS
IP: 20
