Specification
Details
Formatted Capacity2TBForm Factor3.5-inchAdvance Format (AF)YESROHS CompliantYES
Performance
Interface transfer rate (max)
Buffer to host6 Gb/sHost to/from drive (sustained)145 MB/sCache (MB)64Performance Class5400 RPM Class
Reliability / Data Integrity
Load / Unload Cycles300,000Non-recoverable read errors per bits read<1 in 10
Power Management
Average Power Requirements (W)
Read / Write4.4Idle4.1Standby and Sleep0.4
Environmental Specifications
Temperature ( °C, on the base casting)
Operating0 to 65Non Operating-40 to 70Shocks (Gs)
Operating (2 ms, read/write)30Operating (2 ms, read)65Non Operating (2 ms)250Acoustics (dBA)
Idle23Seek (Average)24
Physical Dimensions
Height (in./mm, max)1.028 / 26.1Length (in./mm,max)5.787 / 147Width (in./mm. ±.01 in.)4 / 101.6Weight (lb/kg, ± 10%)1.40 / 0.64
