Schneider Sub Breaker - 1 Line - 10 Amp - ACTI9 iC60N A9F44110, C Curve

The Schneider Acti9 iC60N miniature circuit breaker provides reliable protection against overloads and short circuits. With advanced protection technology and a durable design, it is an ideal choice for residential and commercial electrical panels to ensure system safety and continuous operation.

Specifications

• Brand: Schneider
• Product Type: ACTI9 iC60N Miniature Circuit Breaker
• Model Number: A9F44110
• Current Rating: 10 A
• Number of Poles: 1
• Additional Detail: C Curve

Features

• Single-pole MCB with 10 A rated current and C trip curve
• Breaking capacity up to 10 kA at 220–240 V per EN/IEC 60947-2 and 6 kA per EN/IEC 60898-1
• VisiTrip indicator helps quickly identify the faulty circuit and reduce maintenance time
• VisiSafe green strip ensures physical contact opening for safer maintenance
• Long service life with electrical endurance up to 10,000 cycles and mechanical endurance up to 20,000 cycles

Uses

• Protecting residential electrical panels and branch circuits such as lighting, sockets, and household appliances
• Suitable for commercial buildings to protect circuits serving offices, shops, and facilities
• Ideal for light industrial applications to protect small equipment and machines
• Used in electrical power distribution systems to manage and protect circuit loads
• Can be used in solar power systems to protect circuits connected to solar panels and components

FAQ

Is this breaker suitable for residential use?

Yes, it is ideal for protecting branch circuits in residential electrical panels such as lighting and socket circuits.

Does the breaker protect against short circuits and overloads?

Yes, it is designed to protect electrical circuits from both short circuits and overload currents.

Can it be used in solar power systems?

Yes, it can be used to protect circuits connected to solar power installations.
