DEWALT 18V Compact Hammer Drill Driver – DCD776S2 – 220V Charger

The DEWALT DCD776S2 is a compact cordless hammer drill driver powered by an 18V XR Li-Ion battery system. It is suitable for drilling and fastening applications in wood, metal, and masonry, with two speed settings and a 13mm chuck.

Specifications

• Brand: DEWALT
• Product type: Cordless Hammer Drill Driver
• Model: DCD776S2
• Voltage: 18V
• Battery type: XR Lithium-Ion
• Batteries included: 2
• Battery capacity: 1.5Ah
• Chuck capacity: 1.5–13mm
• Maximum hard torque: 42Nm
• Maximum soft torque: 24Nm
• No-load speed: 0–450 / 1500 rpm
• Impact rate: 0–7650 / 25500 bpm
• Maximum drilling in wood: 30mm
• Maximum drilling in metal: 13mm
• Maximum drilling in masonry: 13mm
• Power output: 300W
• Charger: Multi-voltage / 220V package as supplied
• Carrying case: Included in the standard DCD776S2 kit.

Features

• Compact design for working in confined spaces.
• Two speed settings with variable speed control.
• 15-position adjustable torque control.
• 13mm single-sleeve chuck with spindle lock.
• Supplied with two batteries for improved working continuity.

Applications

• Wood drilling.
• Metal drilling.
• Hammer drilling in compatible masonry.
• Screwdriving and fastening.
• Installation, maintenance, and carpentry work.

FAQs

What voltage is the DCD776S2?

The tool operates on an 18V XR Li-Ion battery platform.

How many batteries are included?

The standard DCD776S2 kit includes two 1.5Ah batteries, a charger, and a carrying case.

What is the maximum torque?

Maximum hard torque is 42Nm, with soft torque up to 24Nm.
