G40 Gas Meter

🔧 Honeywell BK-G40 Gas Meter

High-capacity commercial / industrial diaphragm gas meter by Honeywell (Elster), engineered for accurate measurement of natural gas, LPG, and manufactured gases. The BK-G40 features a fully steel-built body, internally and externally coated against corrosion, and is suitable for both primary and secondary metering.

Technical Specifications:

• Model: BK-G40 U65
• Flow Range: 0.4 – 65 m³/h
• Max Pressure: 0.5 bar (HTB fireproof 0.1 bar)
• Temperature Range: –10 °C to +40 °C
• Connection: Flanged PN16 – DN 65
• Standard: EN 1359 / MID approved by PTB
• Pulse Output: 1 pulse / 0.10 m³ (optional IN-Z61 module)
• Weight: 28 kg
• Origin: Made in Germany – Elster Honeywell

Key Features:

• High-accuracy gas measurement for commercial & industrial applications
• Corrosion-resistant steel construction with internal and external coating
• Optional pulse output (IN-Z61) installable without disturbing calibration seal
• Swivel nuts for easy installation and maintenance
• Compliant with EN 1359 and MID certification

No delivery, pick up from branch only

For inquiries, contact us on

0508191030
