JBL VTX V25-II-CS 4000W 3-way Line Array speakers with compression suspension for stunning sound coverage and exceptional performance

JBL VTX V25-II-CS 4000W 3-way Line Array speakers with compression suspension for stunning sound coverage and exceptional performance

• It is considered The JBL VTX V25-II-CS party speakers are the latest evolution in professional audio systems from the VTX series, combining tremendous power, high-fidelity sound, and superior ease of installation thanks to the innovative Compression Suspension System (CS).
• It was specifically designed to deliver a powerful, consistent sound that covers long distances without losing detail, making it the ideal choice for large shows, theaters, festivals, and huge event halls.
• Large speakers feature a 3-way line array design that includes:
• Two 15-inch speakers with Differential Drive® technology for powerful bass frequencies,
• Four 8-inch speakers for mid-range frequencies,
• And three D2 Dual Diaphragm Compression Drivers for high frequencies.
• It is also equipped with the fourth generation of HF Waveguide technology to improve sound propagation and high-precision sound wave control, making it capable of covering large theaters without any frequency distortion.

Technical description:

• The VTX V25-II-CS party speakers come as a direct improvement on the V25-II release, with the addition of an all-new Compression Suspension System that facilitates vertical mounting and increases the stability of the speaker array during suspension.
• It is integrated to work in perfect harmony with Crown I-Tech HD amplifiers, BSS OmniDriveHD V5 Processing, and JBL HiQnet Performance Manager™ software for intelligent control and rapid system configuration.
• Operating system:
• Line Array 3-Way High-Directivity.
• Audio components:
• LF (Bass): 2 x 15 inch (JBL 2267H Differential Drive®).
• MF (Mid-Frequency): 4 x 8 inch (JBL 2168H Mid-Frequency).
• HF (High): 3 x D2 Dual Diaphragm Dual Voice Coil Compression Driver.
• Control and processing:
• Crown Audio I-Tech HD amplifiers with V5 DSP processing.
• Full support for HiQnet Performance Manager™ software for system management and audio distribution control.
• Structure:
• A combination of Finnish birch wood and a cast aluminum front panel to reduce weight and improve cooling.
• Coated with DuraFlex™ weather and scratch resistant paint.

Technical specifications:

• Type: Three-way Line Array system
• Electrical power: 4000 watts (2000 x 2)
• Frequency range (-10 dB): 35 Hz – 18 kHz
• Horizontal coverage (-6 dB): 90° (200 Hz – 16 kHz)
• Maximum sound pressure (SPL):
• LF: 141 dB
• MF: 140.5 dB
• HF: 149.5 dB
• Amplifiers: Crown Audio I-Tech HD
• Nominal impedance:
• LF: 2 x 8 ohms
• MF: 8 ohms
• HF: 8 ohms
• Audio components:
• LF: (2) JBL 2267H – 15 inch
• MF: (4) JBL 2168H – 8 inch
• HF: (3) JBL 2430K D2 Dual Diaphragm
• Structure:
• cast aluminum front panel
• Finnish birch wood frame with black DuraFlex™ coating
• Unit conversion angles: 0°, 0.5°, 0.75°, 1°, 2°, 3°, 4°, 5°, 6°, 9°
• Dimensions (height x width x depth):
• 414 × 1223 × 614 mm
• (16.3 × 48.2 × 24.2 inches)
• Net weight: 82.6 kg (182 lbs)

Key features:

• A new compression suspension system for faster and safer assembly.
• Waveguide 4th generation for long-range coverage and exceptional sound clarity.
• Differential Drive® technology to reduce weight and increase cooling efficiency.
• D2 Dual Diaphragm amplifiers deliver stunning clarity at high frequencies.
• Aluminum front structure reduces weight and vibrations.
• High operating efficiency with Crown I-Tech HD amplifiers and V5 DSP processing.
• A 90° coverage angle is ideal for uniform distribution in large spaces.
• DuraFlex™ coating is resistant to scratches and heavy use.
• Reliable performance in both indoor and outdoor environments.

Product summary:

• The JBL VTX V25-II-CS large speakers combine advanced engineering design with superior sound performance, making them the ideal solution for large professional audio systems.
• Thanks to the new pressure suspension system, it can be installed easily and safely, while maintaining a uniform sound distribution in all directions.
• It is designed to deliver a powerful and deep sound, suitable for large parties, festivals, and corporate events that require high accuracy and consistency in performance.

Additional features:

• Compatible with cardioid systems when combined with VTX Subwoofer units.
• The ability to precisely adjust angles to achieve optimal sound propagation.
• Designed for large vertical displays with enhanced accessories for rapid vertical transport.
• The V5 DSP processing allows for precise adjustment of each bandwidth.
• Reliable performance even in intensive long-term use.
• Designed to reduce vertical height and improve horizontal spread.

Applications used for the product:

• Massive live music performances and festivals.
• Sports stadiums and large event halls.
• Professional theaters and opera houses.
• Fixed installations in large acoustic halls.
• Audio rental companies and large events.

Summary and final advice:

• If you are looking for a 4000-watt, three-way Line Array party speaker system that combines top-tier audio performance with the latest acoustic suspension and diffusion technologies, the JBL VTX V25-II-CS large speakers are your ideal choice.
• Thanks to its sophisticated design and advanced technology, this headset offers an exceptional audio experience that combines deep bass, high clarity, and wide distribution.
