Electrific Brass Cable Gland Kit with Locknut Earth Tag LSF Shroud High quality Brand electrific

A1A2 M20S/16 Electrific Brass Cable Gland Kit with Locknut Earth Tag LSF Shroud

Gland Sizes : M16 to M100 also available in NPT

Ingress Protection : IP66

Gland Material : Brass, Nickel Plated Brass

Sealing Type : Single Sealing

Operating Temperature : Neoprene -40oC to +100oC Silicone -50oC to +135oC

Plastic Ring Material : Nylon 66

Sealing Method : Displacement Sealing

Sealing Area : Cable Outer Sheath

Finish : Natural Brass or Nickel Plated Brass

Cable Types : Unarmoured

Application : Indoor and Outdoor

Accessories : Lock Nut, Shrouds, IP Washer

Grade of Brass : CuZn39Pb3 / IS 319

Copper+Nickel Content : 56.0 - 59.0%

Zinc : Remainder%

Lead : 2 -3.5%

Iron : 0.35% Max

Total Impurities : 0.4% / 0.7%

Brass Kit : Brass Cable Gland, Brass Lock Nut, IP Washer, Shrouds.

Nickel Plated Brass Kit : Nickel Plated Brass, Cable Gland, Nickel Plated Lock Nut, IP washer, Shrouds.

Product Application:

The A2 type brass cable gland, suitable for

both indoor and outdoor use, is designed for

all unarmoured cables, offering secure mechanical

retention and an effective environmental

seal around the cable’s outer sheath.
