Zoom H6essential 6-Track Portable Recorder with 32-Bit Float Technology and Interchangeable Mic Capsules
1667.50ر.س
Product description
Zoom H6essential Portable Recorder provides advanced multitrack recording with 32-bit float technology, ideal for podcasts, music, and field work.
Key Features
- ✓6-track 32-bit float recorder with Dual A/D Converters
- ✓Clip-free recording with no need to set gain
- ✓Records up to 96kHZ sample rate
- ✓Interchangable Mic Capsule System 3.0 with 32-bit float support
- ✓Included X/Y Mic Capsule captures up to 135 dB SPL
- ✓4 XLR/TRS combo inputs with locking connector
- ✓Color LCD Screen
- ✓Built-in mixer to adjust each track’s audio level
- ✓Built-in speaker for quick reference playback
- ✓3.5mm headphone output plus 3.5mm line output
- ✓Voice Guidance accessibility for the visually impaired
- ✓32-Bit Float audio interface for PC, Mac, iOS, and Android devices via USB-C port
- ✓Use as an interface and record to SD card simultaneously
- ✓Using the BTA-1* Bluetooth Adapter, sync with wireless timecode devices via bluetooth
- ✓Use the BTA-1* Bluetooth Adapter to pair with the H6essential Control App for iOS
- ✓Record to SD cards up to 1TB
- ✓10 hours of battery life on AA battery (4x) or USB-C Bus Power
Specifications
| Specification | Details |
|---|---|
| INPUT AND OUTPUT CHANNELS - Inputs | ['Mic capsule', '1'] |
| INPUT AND OUTPUT CHANNELS - MIC/LINE (mono) | 4 |
| INPUT AND OUTPUT CHANNELS - Outputs | ['LINE OUT', '1'] |
| INPUT AND OUTPUT CHANNELS - Headphones | 1 |
| INPUT AND OUTPUT CHANNELS - Built-in speaker (mono) | 1 |
| INPUTS - XY mic: XYH-6e | 90º XY stereo format |
| INPUTS - Directionality | Unidirectional |
| INPUTS - Sensitivity | −42dB/1Pa at 1kHz |
| INPUTS - Maximum sound pressure input | 135 dB SPL |
| INPUTS - MIC/LINE (mono) | ['Connectors', '4 XLR/TRS combo jacks'] |
| INPUTS - MIC/LINE (mono) | (XLR：2 HOT TRS：TIP HOT） |
| INPUTS - Input gain | Adjustment unnecessary (dual A/D converter circuits used) |
| INPUTS - Input impedance | MIC (XLR) : 3.8 kΩ or more |
| INPUTS - Input impedance | LINE (TRS) : 39 kΩ or more |
| INPUTS - Maximum input level | MIC (XLR) : +4 dBu |
| INPUTS - Maximum input level | LINE (TRS) : +24 dBu |
| INPUTS - Phantom power | +48 V |
| INPUTS - Phantom power | Channel total 32 mA or less |
| INPUTS - Equivalent input noise | MIC (XLR) : -120 dBu or less（IHF-A) @150 Ω input |
| INPUTS - Equivalent input noise | LINE (TRS) : -95 dBu or less（IHF-A) @600 Ω input |
| OUTPUTS - LINE OUT | ['Connector', 'Stereo mini jack'] |
| OUTPUTS - Maximum output level | +1 dBu |
| OUTPUTS - Output impedance | 110 Ω or less |
| OUTPUTS - Headphones | ['Connector', 'Stereo mini jack'] |
| OUTPUTS - Maximum output level | 20 ｍW + 20 ｍW（when 32 Ω load） |
| OUTPUTS - Output impedance | 10 Ω or less |
| OUTPUTS - Built-in speaker | ['Type', '20 mm x 30mm elliptical dynamic speaker'] |
| OUTPUTS - Effective maximum output | 250mW |
| RECORDER - Maximum simultaneous recording tracks | 8 |
| RECORDER - Maximum simultaneous playback tracks | 6 |
| RECORDER - Recording formats | WAV |
| RECORDER - Recording formats | 44.1/48/96 kHz, |
| RECORDER - Recording formats | 32-bit float mono/stereo |
| RECORDER - Recording formats | BWF and iXML formats supported |
| RECORDER - Recording media | 4-32GB cards compatible with the microSDHC specification |
| RECORDER - Recording media | 64GB–1TB cards compatible with the microSDXC specification |
| DISPLAY - 2.0-inch full-color LCD | 360 x 240 |
| USB - Connector | USB Type-C |
| USB - Connector | • Use a USB cable that supports data transfer. |
| USB - Audio Interface | USB 2.0 High Speed |
| USB - Input and output channels | 6 in / 2 out (Multi) |
| USB - Input and output channels | 2 in / 2 out (Stereo) |
| USB - Sampling frequency | 44.1/48/96 kHz (AIF only) |
| USB - Sampling frequency | 44.1/48 kHz (AIF + onboard recording) |
| USB - Bit depth | 24-bit, 32-bit float |
| USB - File transfer | USB 2.0 High Speed |
| REMOTE - Dedicated wireless adapter | ZOOM BTA-1 |
| POWER - 4 AA batteries | Alkaline, lithium or rechargeable NiMH batteries |
| POWER - AC Adapter | ZOOM AD-17 (DC 5 V/1 A) |
| POWER - AC Adapter | • USB bus power is supported. |
| ESTIMATED CONTINUOUS OPERATION TIMES USING BATTERIES : 2-track recording (XYH-6e) - Alkaline batteries | About 18 hours |
| ESTIMATED CONTINUOUS OPERATION TIMES USING BATTERIES : 2-track recording (XYH-6e) - NiMH batteries (1900 mAh) | About 14.5 hours |
| ESTIMATED CONTINUOUS OPERATION TIMES USING BATTERIES : 2-track recording (XYH-6e) - Lithium batteries | About 30 hours |
| ESTIMATED CONTINUOUS OPERATION TIMES USING BATTERIES : 6-track recording (XYH-6e and inputs 1–4) - Alkaline batteries | About 3.5 hours |
| ESTIMATED CONTINUOUS OPERATION TIMES USING BATTERIES : 6-track recording (XYH-6e and inputs 1–4) - NiMH batteries (1900 mAh) | About 4 hours |
| ESTIMATED CONTINUOUS OPERATION TIMES USING BATTERIES : 6-track recording (XYH-6e and inputs 1–4) - Lithium batteries | About 9 hours |
| Power consumption | 5 W maximum |
| Dimensions | Recorder: 78.1 mm (W) × 160.1 mm (D) × 42.8 mm (H) |
| Dimensions | XYH-6e: 69.1 mm (W) × 50.8 mm (D) × 43.0 mm (H) |
| Weight | Recorder: 381 g (including batteries) |
| Weight | XYH-6e: 42 g |
