ASUS Prime H510M-K R2.0 Intel H510 LGA 1200 Socket micro Atx Motherboard

A micro‑ATX motherboard that supports the latest 10th and 11th Gen Intel processors, featuring PCIe 4.0 and a high-speed M.2 slot up to 32 Gbps, along with robust 5X Protection III safeguards. Designed to deliver a stable build, intelligent cooling, and reliable long-term performance.

Features:

• Full support for 10th and 11th Gen Intel® processors with LGA 1200 socket, including Turbo Boost 2.0 and Max 3.0 technologies.
• One PCIe 4.0 x16 slot (with 11th Gen CPUs) for high-performance graphics cards.
• High-speed M.2 slot (2242/60/80) via PCIe 3.0 x4 or SATA, with Intel Optane Memory support.
• Realtek 1Gb Ethernet and versatile USB connectivity, including USB 3.2 Gen 1.
• Comprehensive protection including DIGI+ VRM, LAN Guard, SafeSlot Core, and corrosion-resistant stainless steel I/O shield under ASUS 5X Protection III.
• Enhanced cooling with H470 chipset heatsink, fully compatible with ASUS Fan Xpert software.
• Intelligent software management via Armoury Crate and AI Suite 3, with user-friendly BIOS and Enhanced Memory Profile (AEMP) for DDR4 optimization.

Specifications:

• Product Name: ASUS Prime H510M-K R2.0 Intel H470 LGA 1200 Socket micro Atx Motherboard
• Model Number: 90MB1E80-M0EAY0
• Brand: ASUS
• Color: Black
• Compatibility:
• Processors: Intel® LGA 1200 – Supports 10th and 11th Gen Core, Pentium Gold, Celeron
• Memory: 2× DDR4 DIMM slots, up to 64 GB, speeds up to 3200 MHz (OC)
• Video Outputs:
• VGA (15‑pin), HDMI (up to 4K@60Hz with 11th Gen or 4K@30Hz with 10th Gen)
• Expansion Slots:
• 1× PCIe 4.0/3.0 x16
• 1× PCIe 3.0 x1
• Storage:
• 1× M.2 (Key M, PCIe 3.0×4 / SATA)
• 4× SATA 6 Gb/s
• USB Ports:
• Rear: 4× USB 3.2 Gen 1 Type‑A, 2× USB 2.0 Type‑A
• Internal: 1× USB 3.2 Gen 1 header (supports 2 additional ports), 2× USB 2.0 headers (supports 4 additional ports)
• Audio:
• Realtek 7.1 HD Audio Codec, 24‑Bit/192 kHz support, audio shielding, premium capacitors, PCB audio isolation layers
• Networking:
• Realtek Gigabit Ethernet RJ‑45
• Internal Connectors:
• Cooling: 1× 4-pin CPU fan, 1× 4-pin chassis fan
• Power: 1× 24‑pin main, 1× 8‑pin +12V
• RGB header, Clear CMOS, COM port, front panel audio (AAFP), PS/2 combo
• Dimensions: 22.6 × 20.3 cm (~8.9 × 8.0 inches)
• Box Contents:
• Motherboard
• I/O shield
• 2× SATA 6Gb/s cables
• User manual
• M.2 screw package

With these solid specifications, the ASUS Prime H510M-K R2.0 is an excellent choice for building a modern desktop on a budget, offering a great balance of performance, reliability, and easy customization.
