3-Pin Two-Position Slide Switch – 3mm or 5mm

A compact three-pin slide switch for manual switching in electronic circuits. Its slider moves between two positions, while the pins are connected according to the required circuit function.

Available in 3mm and 5mm sizes, so you can choose the option that fits your project or replacement part. The metal body, black slider, and three solder pins make it suitable for electronic boards and compact projects.

Specifications:

• Type: Slide switch.
• Number of pins: 3.
• Switching positions: 2.
• Available sizes: 3mm and 5mm.
• Mounting: Soldered pins for circuit or PCB installation.
• Appearance: Metal body with a black slider.

Features:

• Compact size for limited spaces.
• Slider moves between two switching positions.
• Three pins for circuit connections.
• Available in two size options.

Applications:

• Electronics and hobby projects.
• Basic control and switching circuits.
• Small electronic devices.
• Replacement of compatible slide switches in boards and devices.

Selection and installation notes:

• Select either the 3mm or 5mm option.
• Check the pin layout and switch dimensions against your board before installation.
• Voltage and current ratings were not provided; use the switch within the requirements of the circuit.

Approximate weight:

1g.
