DLINK DGS-F1210-26PS-E 26-port Switch, 10/100/1000Base-T, Long Range 250m, PoE+, Smart Switch with 24 PoE Ports, 2 SFP Ports | DGS-F1210-26PS-E

نظرة عامة:
D-Link DGS-F1210-26PS-E 26-Port Gigabit Smart Managed Long Range PoE + Switch

الوصف والمميزات:
DLINK DGS-F1210-26PS-E 26-port Switch
The DGS-F1210-26PS-E supports both IEEE 802.3at and IEEE 802.3af PoE protocol. With a total PoE budget of 250 watts, allowing users to attach an IEEE 802.3af-compliant device to the DGS-F1210-26PS-E without requiring additional power. PoE is especially suitable for devices that are far from power outlets or when users want to minimize the clutter of extra cables as power is supplied via the Ethernet cables themselves.
Specifications
General
Network Interfaces
- 24 x 10/100/1000 Mbps PoE RJ45 Ports (Port 1 to Port 24)
- 2 x Gigabit SFP Ports
Console Port
Yes
DIP Switches
VLAN, Extend, PoE Qas
Transmission Rate
10/100/1000 Mbps, with MDI/MDIX Auto-Flip and Auto-Negotiation
Protocols and Standards
- IEEE 802.3: 10BASE-T, 1000BASE-X
- IEEE 802.3u: 100BASE-TX
- IEEE 802.3x: Flow Control
- IEEE 802.3af/at PoE Standards
- ANSI/IEEE 802.3 NWay Auto-Negotiation
- IEEE 802.3ab: 1000BASE-T
Switching Capacity
52 Gbps
Packet Forwarding Rate
38.688 Mpps
MAC Address Table
8K Entries
Power Budget
250W
Lightning Protection
6KV
Physical
Dimensions
440 x 180 x 44 mm
Weight
3.2 kg
Power
100-240VAC, 50-60Hz
LED Indicators
Power, SYS, LINK/ACT, PoE
Environmental Parameters
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Operating Humidity: 10% to 90% non-condensing
